Professional Cyclone Dust Collector for Cement Kiln Separator Customized

Professional Cyclone Dust Collector for Cement Kiln Separator Customized
Professional Cyclone Dust Collector for Cement Kiln Separator Customized Professional Cyclone Dust Collector for Cement Kiln Separator Customized Professional Cyclone Dust Collector for Cement Kiln Separator Customized Professional Cyclone Dust Collector for Cement Kiln Separator Customized Professional Cyclone Dust Collector for Cement Kiln Separator Customized Professional Cyclone Dust Collector for Cement Kiln Separator Customized

Large Image :  Professional Cyclone Dust Collector for Cement Kiln Separator Customized

Product Details:
Place of Origin: Hebei, China
Brand Name: YITE
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $1,700.00/pieces 1-3 pieces
Packaging Details: cyclone dust collector transport by container.
Supply Ability: 100 Set/Sets per Year
Contact Now

Professional Cyclone Dust Collector for Cement Kiln Separator Customized

Description
Applicable Industries: Other Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2021 Warranty Of Core Components: 1 Year
Core Components: Gear Condition: New
Minimum Particle Size: 0.3Micron Dimension(L*W*H): 460*390*1380(m'm)
Weight: 55 Kg Warranty: 1year
Product Name: Cyclone Dust Collector Application: Dust Filtration,air Purification
Material: Carbon Steel Structure: Box-type
AIr Volume: 750-1060 M3 / H Customized: Accept
Sample: Pay For Sample OEM: Yes
ODM: Yes Color: Custom
Port: TIANJIN

Professional Cyclone Dust Collector for Cement Kiln Separator Customized 0
The cyclone dust collector is a dry filter dust collector. When the dust is drawn into the cyclone dust collector by the
centrifugal fan, it will rotate from top to bottom along the wall. Therefore, the dust particles are separated from the airflow by the centrifugal force, and then fall into the ash hopper along the wall by gravity, and the gas will be discharged from the
discharge pipe upwards along the discharge pipe.

Cyclone dust collector is applicable to the removal of non-viscous and non-fibrous dust, which is mostly used to remove
particlesabove 5μm, and the parallel multi-tube cyclone deduster device also has the dust removal efficiency of 80-85% for
particles at3μm.
Our Advantages
1.The equipment has small volume, simple structure, small floor space, low cost, small equipment resistance and large air volume;
2.No rotating mechanism and moving parts, convenient maintenance and management, no technical requirements;
3. can be used for the purification of high-temperature dusty gas
4.Dry dust removal is beneficial to the recovery of valuable dust;
5.Wide range of applications. Wear-resistant and corrosion-resistant linings are installed in the dust collector, which can be used to purify the flue gas containing highly corrosive dust.
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 1
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 2

model
diameter
(mm)
Air volume(m³/h)
highly(mm)
Air inlet
no flange
outlet
no flange
weight
(kg)

thickness
(mm)
normal
max
With stents
no stents
YTXF-280
280
600
1000
800
-200
φ108
φ140
15
2
YTXF-400
400
1300
2000
1600
-400
φ160-200
φ200
45
2
YTXF-500
500
2000
3200
2000
φ200-250
φ250
65
2
YTXF-600
600
3200
4600
2400
-800
φ250-300
φ300
95
2
YTXF-800
800
4600
8200
3200
φ300-400
φ400
190
2.5
YTXF-1000
1000
8200
12000
4000
φ400-500
φ500
310
2.5
YTXF-1200
1200
12000
18000
4800
φ500-600
φ600
430
2.5
YTXF-1300
1300
18000
21000
5200
φ600-650
φ650
520
2.5
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 3
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 4
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 5
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 6
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 7
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 8
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 9
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 10
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 11
Professional Cyclone Dust Collector for Cement Kiln Separator Customized 12
FAQ
Q1.Are you a factory and trading company?
A: We are a factory

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. Can you suggst me a suitable type?
A: Certainly, Once you give me the keyword. The most suitable size will be choose to meet your need

Q4. How about your delivery time?
A: Generally, it will take 7-30 days after receiving your advance payment. The specific delivery time depends on the items ,
transportation ways and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they comefrom.
